| Model |
SUN-SMART-PLUG01-F |
| Electrical Parameters |
|
| Rated voltage |
220-250V a.c. |
| Maximum current |
16A a.c. |
| Frequency and Range |
50Hz(45Hz-55Hz)/60Hz(55Hz-65Hz) |
| Connection |
Plug-type |
| Communication |
|
| Communication Model |
LoRa |
| Lora Communication Distance |
≈200m (Barrier free) |
| Basic Parameters |
|
| Working Temperature Range |
-40 to +60°C |
| Allow Environmental Humidity |
0-95%RH |
| Ingress Protection (IP) Rating |
IP20 |
| Protection Level |
CLASS I |
| Allowable Altitude |
≤3000m |
| Product size (WxHxD) |
51.2x51.2x64mm |
| Weight |
0.08kg |
| Warranty |
5 Years |
| Standard |
VDE 0620-2-1; EN 61058 |
| LoRa Parameters |
|
| Frequency Range |
863MHz-870MHz |
| Antenna |
Internal antenna |
| Antenna Gain |
0.3.23dBi@868MHz |
