Thanks to the smart monitoring platform, Deye full series inverter products support remotely shutdown immediately when accident occurs.Setting parameters and FW update remotely, which makes PV plant O&M easier.
SUN-BK180-2.0KWH-EU-AM2
SUN-BK200-2.0KWH-EU-AM2
SUN-BK160-2.0KWH-EU-AM4
SUN-BK180-2.0KWH-EU-AM4
SUN-BK200-2.0KWH-EU-AM4
Model | SUN-BK160-2.0KWH-EU-AM2 | SUN-BK180-2.0KWH-EU-AM2 | SUN-BK200-2.0KWH-EU-AM2 | SUN-BK160-2.0KWH-EU-AM4 | SUN-BK180-2.0KWH-EU-AM4 | SUN-BK200-2.0KWH-EU-AM4 |
AC Technical Specification | ||||||
Rated AC Input / Output Active Power | 1600W | 1800W | 2000W | 1600W | 1800W | 2000W |
Max. AC Input / Output Active Power | 1600W | 1800W | 2000W | 1600W | 1800W | 2000W |
AC Input / Output Frequency and Voltage | 50Hz ( 45Hz ~ 55Hz ) , 60Hz ( 55Hz ~ 65Hz ) , L / N ( PE ) , 220 / 230 Vac | |||||
Grid Type | Single phase | |||||
Rated Grid Input / Output Current | 7.3A / 7.0A | 8.2A / 7.9A | 9.1A / 8.7A | 7.3A / 7.0A | 8.2A / 7.9A | 9.1A / 8.7A |
Max.Grid Input / Output Current | 8.0A / 7.7A | 9.0A / 8.7A | 10.0A / 9.6A | 8.0A / 7.7A | 9.0A / 8.7A | 10.0A / 9.6A |
Peak Power ( off-grid ) | 2 time of rated power, 10s | |||||
Power Factor Adjustment Range | 0.8 leading to 0.8 lagging | |||||
Max. Continuous AC Passthrough (grid to load) | 20A | 30A | ||||
DC Injection Current | <0.5%In | |||||
PV String Input Data | ||||||
Max. PV Access Power | 3200W | 3600W | 4000W | 3200W | 3600W | 4000W |
Max. PV Input Power | 2560W | 2880W | 3200W | 2560W | 2880W | 3200W |
Max. Operating PV Input Current | 32A+32A | 16A+16A+16A+16A | ||||
Max. Input Short-Circuit Current | 48A+48A | 24A+24A+24A+24A | ||||
Rated PV Input Voltage | 42.5V ( 20V ~ 55V ) | |||||
Start-up Voltage | 25Vdc | |||||
MPPT Voltage Range | 20 ~ 55V | |||||
No. of MPP Trackers/No. of Strings MPP Tracker | 2/2+2 | 4/1+1+1+1 | ||||
Battery Input Data | ||||||
Battery Type | LiFePO4 | |||||
Max.Charging/Discharging Current | 40A | |||||
Battery Nominal Energy | 2000Wh | |||||
Battery Voltage Range | 40V ~60V | |||||
Charging Strategy for Li-ion Battery | Self-adaption to BMS | |||||
General Data | ||||||
Communication Interfaces | Wi-Fi, Bluetooth, LoRa | |||||
Dimension ( W × D × H ) | 560 × 210 × 331mm | |||||
Operating Temperature Range | -10°C ~ 50°C | |||||
Permissible Altitude | 2000m | |||||
Permissible Ambient Humidity | 0~100% | |||||
Ingress Protection(IP) Rating | IP65 | |||||
Safety EMC / Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |||||
Grid Regulation | IEC 61727,IEC 62116,CEI 0-21,EN 50549,NRS 097,RD 140,UNE 217002, OVE-Richtlinie R25,G98,VDE-AR-N 4105 |
|||||
Battery Certification | UN38.3, IEC 62619 | |||||
Installation Style | Floor-Mounted | |||||
Warranty | 10 years | |||||
Model | AE-F2.0 | |||||
Battery Technical Specification | ||||||
Battery Chemistry | LiFePO4 | |||||
Battery Nominal Voltage | 51.2V | |||||
Battery Nominal Energy | 2000Wh | |||||
Max. Charging / Discharging Current | 40A | |||||
Battery Operating Voltage | 40V ~ 60V | |||||
Battery Cycle Life | ≥6000 ( @25°C±2°C, 0.5C / 0.5C, 70%EOL ) | |||||
Parallel Capability | 5 pcs* | |||||
Other Technical Specification | ||||||
Display | LED ( SOC, Alarm ) | |||||
Communication Interfaces | CAN2.0, LoRa | |||||
Dimension ( W × D × H ) | 450 × 210 × 244mm | |||||
Weight Approximate ( kg ) | 20 | |||||
Operating Temperature Range | -10°C ~ 50°C | |||||
Max. Operating Altitude | 2000m | |||||
Relative Humidity | 0% ~ 95% ( No Condensing ) | |||||
Certification | UN38.3, IEC 62619, CE | |||||
Installation Style | Floor-Mounted | |||||
Warranty | 10 years |
