| Model |
SUN-M130G4-EU-Q0 |
SUN-M160G4-EU-Q0 |
SUN-M180G4-EU-Q0 |
SUN-M200G4-EU-Q0 |
SUN-M220G4-EU-Q0 |
SUN-M180G4-EU-Q0-P |
SUN-M200G4-EU-Q0-P |
| PV String Input Data |
|
| Max. PV Input Power(W) |
210-460(4 Pieces) |
210-560(4 Pieces) |
210-630(4 Pieces) |
210-700(4 Pieces) |
210-770(4 Pieces) |
210-630(4 Pieces) |
210-700(4 Pieces) |
| Max. PV Input Voltage(V) |
60 |
| Start-up Voltage(V) |
20 |
| MPPT voltage range(V) |
25-55 |
| Rated PV Input voltage(V) |
42.5 |
| Max. Operating PV Input Current (A) |
15+15+15+15 |
18+18+18+18 |
| Max. Input Short Circuit Current (A) |
22.5+22.5+22.5+22.5 |
27+27+27+27 |
| No. of MPP Trackers/No. of String per MPP Tracker |
4/1 |
| AC Input/Output Side |
|
| Rated AC Output Active Power(W) |
1300 |
1600 |
1800 |
2000 |
2200 |
1800 |
2000 |
| Max.AC Output Apparent Power(VA) |
1300 |
1600 |
1800 |
2000 |
2200 |
1800 |
2000 |
| Rated AC output current (A) |
6/5.7 |
7.3/7 |
8.2/7.9 |
9.1/8.7 |
10/9.6 |
8.2/7.9 |
9.1/8.7 |
| Max.AC Output Current(A) |
6/5.7 |
7.3/7 |
8.2/7.9 |
9.1/8.7 |
10/9.6 |
8.2/7.9 |
9.1/8.7 |
| Rated output voltage/range (V) |
220/230 0.85Un-1.1Un |
| Grid Connection Form |
L/N/PE |
| Rated Output Grid Frequency/range(Hz) |
50/45-55, 60/55-65 |
| Max. unit per branch |
5 |
4 |
3 |
3 |
3 |
3 |
3 |
| Power Factor Adjustment Range |
0.9 leading to 0.9 lagging |
| Total Current Harmonic Distortion THDi |
<3% |
| DC Injection Current |
<0.5%ln |
| Efficiency |
|
| Max. Efficiency |
96.50% |
| Euro Efficiency |
96 |
| MPPT Efficiency |
>99% |
| Equipment Protection |
|
| DC Polarity Reverse Connection Protection |
YES |
| AC Output Overcurrent Protection |
YES |
| AC Output Overvoltage Protection |
YES |
| AC Output Short Circuit Protection |
YES |
| Thermal Protection |
YES |
| DC Terminal Insulation Impedance Monitoring |
YES |
| Power Network Monitoring |
YES |
| Island protection monitoring |
YES |
| Earth Fault Detection |
YES |
| Overvoltage Load Drop Protection |
YES |
| Interface |
|
| Communication Interface |
WiFi |
| General Data |
|
| Operating Temperature Range (°C) |
-40 to +65℃, >45℃ Derating |
| Permissible Ambient Humidity |
0~100% |
| Permissible Altitude (m) |
2000m |
| Noise (dB) |
≤ 25 |
| Ingress Protection(IP) Rating |
IP 67 |
| Inverter Topology |
Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
| Cabinet Size（W*H*D）[mm] |
311*250.5*36.5
|
358*255.5*36.5 |
311*250.5*36.5 |
| Weight [kg] |
5.1
|
5.2 |
5.1 |
| Warranty [year] |
10 Years |
| Type Of Cooling |
natural cooling |
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
|
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
