| Model |
SUN-3K-OG03LP1-EU-AM1 |
SUN-3.6K-OG03LP1-EU-AM1 |
SUN-5K-OG03LP1-EU-AM2 |
SUN-6.6K-OG03LP1-EU-AM2 |
SUN-8.8K-OG03LP1-EU-AM2 |
| Battery Input Data |
| Battery Type |
Lead-acid or Lithium-ion |
| Battery Voltage Range (V) |
40-60 |
| Max. Charging/Discharging Current (A) |
70 |
90 |
120 |
140 |
190 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of Battery Input |
1 |
| PV String Input Data |
|
|
| Max. PV Access Power (W) |
6000 |
7200 |
10000 |
13200 |
17600 |
| Max. PV Input Power (W) |
4800 |
5760 |
8000 |
10560 |
14080 |
| Max. PV Input Voltage (V） |
500 |
| Start-up Voltage (V) |
125 |
| MPPT Voltage Range(V） |
150-425 |
| Rated PV Input Voltage (V) |
370 |
| Max. Operating PV Input Current (A） |
18 |
18+18
|
36+18 |
| Max. Input Short-Circuit Current (A) |
27 |
27+27
|
54+27 |
| No. of MPP Trackers/No. of Strings MPP Tracker |
1/1 |
2/1+1 |
| AC Output Data |
|
|
| Rated AC Output Power (VA/W) |
3000 |
3600 |
5000 |
6600 |
8800 |
| Max. AC Output Power (VA/W) |
3000 |
3600 |
5000 |
6600 |
8800 |
| Max. AC Output Current (A) |
13.1 |
15.7 |
21.8 |
28.7 |
38.3 |
| Rated AC Output Current (A) |
13.1 |
15.7 |
21.8 |
28.7 |
39.3 |
| Peak Power (W） |
2 times of rated power, 10s |
| Rated Output Voltage (V) |
230 L+N+PE |
| Rated Output Frequency |
50Hz / 60Hz |
| Output Voltage Waveform |
Pure Sine Wave |
| Total Current Harmonic Distortion THDi |
＜3% |
| AC Input Date(Grid and Generator) |
| Max. Input Power to Battery (W) |
3000 |
3600 |
5000 |
6600 |
8800 |
| Rated Input Voltage (V） |
230 |
| Rated Input Frequency |
50Hz / 60Hz |
| Gird Input Current (A) |
35
|
50 |
| Generator Input Current (A) |
35
|
50 |
| Efficiency |
| Max. Efficiency |
97.6% |
| Euro Efficiency |
96.5% |
| MPPT Efficiency |
>99% |
| Equipment Protection |
| Integrated |
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,Insulation Impedance Detection |
| Surge Protection Level |
TYPE II(DC), TYPE II(AC) |
| Interface |
| LCD/LED Display |
LCD |
| Communication Interface |
Wi-Fi&BT,RS485,CAN |
| General Data |
| Operating Temperature Range (℃) |
-40 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity |
0-100% |
| Permissible Altitude |
3000m |
| Noise (dB) |
<46 |
| Ingress Protection(IP) Rating |
IP 65 |
| Inverter Topology |
Non-Isolated (solar), Isolated (battery) |
| Over Voltage Category |
OVC II(DC), OVC III(AC) |
| Cabinet Size (WxHxD mm) |
323×424×176 (Excluding Connectors and Brackets) |
| Weight (kg） |
8.6 |
| Type of Cooling |
Intelligent Air Cooling |
| Warranty |
Standard 5 years, extendable warranty |
| Safety / EMC Standard |
IEC62109-1/2, EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4 |
