| Model |
SUN-7K-SG06LP1-EU-CM3 |
SUN-7.6K-SG06LP1-EU-CM3 |
SUN-8K-SG06LP1-EU-CM3 |
SUN-10K-SG06LP1-EU-CM3 |
SUN-12K-SG06LP1-EU-CM3 |
| Battery Input Data |
|
| Battery Type |
Lead-acid or Lithium-ion |
| Battery Voltage Range(V) |
40-60 |
| Max. Charging/Discharging Current (A) |
175 |
185 |
185 |
220 |
250 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of battery input |
1 |
| PV String Input Data |
|
|
Max. PV Access Power (W)
|
14000 |
15200 |
16000 |
20000 |
24000 |
| Max DC Input Power（W） |
11200 |
12160 |
12800 |
16000 |
19200 |
| Max DC Input Voltage（V） |
500 |
| Start-up Voltage（V） |
125 |
| MPPT Voltage Range（V） |
150-425 |
| Rated DC Input Voltage(V) |
370 |
| Max. Operating PV Input Current (A) |
36+18+18
|
36+36+18 |
| Max. Input Short-Circuit Current (A) |
54+27+27
|
54+54+27 |
| No.of MPP Trackers/No.of String Per MPP Tracker |
3/2+1+1
|
3/2+2+1 |
| AC Input/Output Data |
|
| Rated AC Input/Output Active Power（W） |
7000 |
7600 |
8000 |
10000 |
12000 |
| Max AC Input/Output Apparent Power （VA） |
7700 |
8360 |
8800 |
11000 |
13200 |
| Rated AC Input/Output Current（A） |
31.9/30.5 |
34.6/33.1 |
36.4/34.8 |
45.5/43.5 |
54.6/52.2 |
| Max AC Input/Output Current（A） |
35/33.5 |
38/36.4 |
40/38.3 |
50/47.9 |
60/57.4 |
| Max Continuous AC Passthrough (grid to load)（A） |
65
|
70 |
| Peak Power (off-grid)（W） |
2 times of rated power,10s
|
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated Input/Output Voltage/Range (V) |
220/230V 0.85Un-1.1Un L+N+PE |
| Rated Input/Output Grid Frequency/Range(Hz) |
50/45-55, 60/55-65 |
| Total Current Harmonic Distortion THDi |
<3% (of nominal power) |
| DC Injection Current |
<0.5%ln |
| Efficiency |
|
| Max Efficiency |
97.6% |
| Euro Efficiency |
96.5% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
|
|
Integrated
|
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit Interrupter (optional), Anti-islanding Protection, DC Switch, Insulation Impedance Detection, Residual Current Detection
|
| Surge Protection Level |
TYPE II(DC),TYPE II(AC) |
| Interface |
|
| LCD/LED Display |
LCD |
| Communication Interface |
WIFI, RS485, CAN |
| General Data |
|
| Operating Temperature Range |
-40 to +60℃, >45℃ Derating
|
| Permissible Ambient Humidity |
0~100% |
| Permissible Altitude |
3000m |
| Noise |
＜45 |
| Ingress Protection(IP) Rating |
IP 65 |
| Inverter Topology |
Non-Isolated (solar), Isolated (battery) |
| Over Voltage Category |
OVC II(DC),OVC IV(AC) |
| Cabinet size（W*H*D）[mm] |
340×580×234（Excluding connectors and brackets） |
| Weight[kg] |
24.6
|
24.9 |
| Warranty |
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy |
| Type Of Cooling |
Intelligent air cooling |
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
