| Model |
SUN-1K-G05P1-EU-AM1 |
SUN-1.5K-G05P1-EU-AM1 |
SUN-2K-G05P1-EU-AM1 |
SUN-2.2K-G05P1-EU-AM1 |
SUN-2.5K-G05P1-EU-AM1 |
SUN-2.7K-G05P1-EU-AM1 |
SUN-3K-G05P1-EU-AM1 |
SUN-3.3K-G05P1-EU-AM1 |
SUN-3.6K-G05P1-EU-AM1 |
SUN-4K-G05P1-EU-AM1 |
| PV String Input Date |
| Max. PV Input Power(kW) |
1.5 |
2.3 |
3 |
3.3 |
3.8 |
4.1 |
4.5 |
5 |
5.4 |
6 |
| Max. PV Input Voltage(V) |
550 |
| Start-up Voltage(V) |
50 |
| MPPT voltage range(V) |
40-500 |
| Rated PV Input voltage(V) |
360 |
420 |
| Max. Operating PV Input Current (A) |
20 |
| Max. Input Short Circuit Current (A) |
30 |
| No. of MPP Trackers/No. of Strings MPP Tracker |
1/1 |
| AC Output Side |
| Rated AC Output Active Power (kW) |
1 |
1.5 |
2 |
2.2 |
2.5 |
2.7 |
3 |
3.3 |
3.6 |
4 |
| Max. AC Output Apparent Power (kVA) |
1.1 |
1.65 |
2.2 |
2.42 |
2.75 |
2.97 |
3.3 |
3.63 |
3.96 |
4.4 |
| Rated AC output current (A) |
4.6/4.4 |
6.8/6.5 |
9.1/8.7 |
10/9.6 |
11.4/10.9 |
12.3/11.8 |
13.7/13.1 |
15/14.4 |
16.4/15.7 |
18.2/17.4 |
| Max. AC Output Current(A) |
5/4.8 |
7.5/7.2 |
10/9.6 |
11/10.6 |
12.5/12 |
13.5/13 |
15/14.4 |
16.5/15.8 |
18/17.3 |
20/19.2 |
| Rated output voltage/range (V) |
220/230 0.85Un-1.1Un |
| Grid Connection Form |
L+N+PE |
| Rated Output Grid Frequency/Range(Hz) |
50/45-55, 60/55-65 |
| Power Factor Adjustment Range |
0.8 leading to 0.8lagging |
| Total Current Harmonic Distortion THDi |
<3% |
| DC Injection Current |
<0.5%ln |
| Efficiency |
| Max. Efficiency |
97.30% |
97.50% |
| Euro Efficiency |
96.90% |
97.00% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
| DC Reverse Polarity Protection |
Yes |
| AC Output Overcurrent Protection |
Yes |
| AC Output Overvoltage Protection |
Yes |
| AC Output Short Circuit Protection |
Yes |
| Thermal Protection |
Yes |
| Insulation Impedance Detection |
Yes |
| DC Component Monitoring |
Yes |
| Arc Fault Circuit Interrupter (AFCI) |
Optional |
| Anti-islanding Protection |
Yes |
| Residual Current Detection |
Yes |
| Surge Protection Level |
TYPE II(DC),TYPE II(AC) |
| DC Switch |
Yes |
| Interface |
| LCD/LED display |
LCD+LED |
| Communication Interface |
RS485/RS232 /WiFi/LAN
|
| General Data |
| Operating Temperature Range (°C) |
-25 to +65℃, >45℃ Derating |
| Permissible Ambient Humidity |
0~100% |
| Permissible Altitude (m) |
2000m |
| Noise (dB) |
≤ 35 |
| Ingress Protection(IP) Rating |
IP 65 |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
| Cabinet Size (WxHxD mm) |
280mm*254.5mm*173mm（Excluding connectors and brackets） |
| Weight [kg] |
5.7 |
| Warranty |
5 Years |
| Type Of Cooling |
natural cooling |
| Grid Regulation |
IEC 61727,IEC 62116,CEI 0-21,EN 50549，NRS 097,RD 140,UNE 217002,G98,G99,VDE-AR-N 4105 |
| Safety EMC/Standard |
IEC/EN 62109-1,IEC/EN 62109-2，IEC/EN 61000-6-1,IEC/EN 61000-6-2,IEC/EN 61000-6-3,IEC/EN 61000-6-4
|
