| Model |
SUN-100K-SG02HP3-EU-GM10 |
SUN-125K-SG02HP3-EU-GM10 |
| Battery Input Data |
| Battery Type |
Lithium-ion |
| Battery Voltage Range(V) |
160-1000 |
| Max.Charging Current(A) |
100+100 |
| Max.Discharging Current(A) |
100+100 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of battery input |
2 |
| PV String Input Data |
| Max. PV Access Power (W) |
200000 |
250000 |
| Max PV Input Power（W） |
160000 |
200000 |
| Max PV Input Voltage（V） |
1000 |
| Start-up Voltage（V） |
180 |
| MPPT Voltage Range（V） |
150-850 |
| Rated PV Input Voltage(V) |
650 |
| Max Input Short-Circuit Current（A） |
42+42+42+42+42+42+42+42+42+42 |
| Max Operating PV Input Current（A） |
63+63+63+63+63+63+63+63+63+63 |
| No.of MPP Trackers/No.of String Per MPP Tracker |
10/2+2+2+2+2+2+2+2+2+2 |
| AC Input/Output Data |
| Rated AC Input/Output Active Power（W） |
100000 |
125000 |
| Max AC Input/Output Apparent Power （VA） |
110000 |
135000 |
| Rated AC Input/Output Current（A） |
151.6/145.0 |
189.4/181.2 |
| Max AC Input/Output Current（A） |
166.7/159.5 |
204.6/195.7 |
| Max Continuous AC Passthrough (grid to load)（A） |
250 |
| Rated Input/Output Voltage/Range(V) |
220/380V，230/400V |
| Grid Connection Form |
3L+N+PE |
| Rated Input/Output Grid Frequency/Range |
50/45-55, 60/55-65 |
| Power Factor Adjustment Range |
0.8 leading-0.8 lagging |
| Total Current Harmonic Distortion THDi |
<3% (of nominal power) |
| DC Injection Current |
<0.5%ln |
| Efficiency |
| Max Efficiency |
98.70% |
| Euro Efficiency |
98.10% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
| Integrated |
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage
Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit
Interrupter (optional), Anti-islanding Protection, DC Switch, Insulation Impedance Detection,
Residual Current Detection |
| Surge Protection Level |
TYPE II(DC), TYPE II(AC) |
| Interface |
| LCD/LED Display |
LCD+LED |
| Communication Interface |
RS485/RS232/CAN |
| Monitor Mode |
GPRS/WIFI/Bluetooth/4G/LAN(optional) |
| General Data |
| Operating Temperature Range |
-40℃+60℃,＞45℃ Derating |
| Permissible Ambient Humidity |
0-100% |
| Permissible Altitude |
3000m |
| Noise |
≤ 65 |
| Ingress Protection(IP) Rating |
IP 65 |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
|
Cabinet Size (WxHxD mm)
|
734×1091×344 (Excluding Connectors and Brackets)
|
| Warranty |
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy |
| Type Of Cooling |
Smart cooling |
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
