| Model |
SUN-15K-SG02HP3-EU-DM3 |
SUN-20K-SG02HP3-EU-DM3 |
SUN-25K-SG02HP3-EU-DM3 |
| Battery Input Data |
|
| Battery Type |
Lithium-ion |
| Battery Voltage Range(V) |
160-700 |
| Max.Charging/Discharging Current(A) |
55 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of Battery input |
1 |
| PV String Input Data |
|
|
Max. PV Access Power (W)
|
30000 |
40000 |
50000 |
| Max. PV Input Power（W） |
24000 |
32000 |
40000 |
| Max. PV Input Voltage（V） |
1000 |
| Start-up Voltage（V） |
180 |
| MPPT Voltage Range（V） |
150-850 |
| Rated PV Input Voltage(V) |
600 |
| Max Input Short-Circuit Current（A） |
36+20+20 |
| Max Operating PV Input Current（A） |
54+30+30 |
| No.of MPP Trackers/No.of Strings MPP Tracker |
3/2+1+1 |
| AC Input/Output Data |
|
| Rated AC Input/Output Active Power（W） |
15000 |
20000 |
25000 |
| Max. AC Input/Output Apparent Power （VA） |
16500 |
22000 |
27500 |
| Rated AC Input/Output Current（A） |
22.8/21.8 |
30.4/29.0 |
37.9/36.3 |
| Max. AC Input/Output Current（A） |
25/24 |
33.4/31.9 |
41.7/39.9 |
| Max. Continuous AC Passthrough (grid to load)（A） |
60 |
| Peak Power (off-grid)（W） |
1.5 times of rated power,10s |
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated input/output voltage |
220/380V,230/400V 0.85Un-1.1Un 3L+N+PE |
| Rated Input/Output Grid Frequency/Range(Hz) |
50/45-55, 60/55-65 |
| Total Current Harmonic Distortion THDi |
<3% (of nominal power) |
| DC Injection Current |
<0.5%ln |
| Efficiency |
|
| Max. Efficiency |
97.6% |
| Euro Efficiency |
97.0% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
|
|
Integrated
|
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage
Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit
Interrupter (optional), Anti-islanding Protection, DC Switch, Insulation Impedance Detection,
Residual Current Detection
|
| Surge Protection Level |
TYPE II(DC), TYPE II(AC) |
| Interface |
|
| LCD/LED Display |
LCD+LED |
| Communication Interface |
WIFI, RS485, CAN |
|
Monitor Mode
|
GPRS/WIFI/Bluetooth/4G
|
| General Data |
|
| Operating Temperature Range (℃) |
-40 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity |
0-100% |
| Permissible Altitude |
3000m |
| Noise (dB) |
≤45 |
| Ingress Protection(IP) Rating |
IP 65 |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
| Type of Cooling |
Intelligent Air Cooling |
| Warranty |
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy |
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
