| Model |
SUN-5K-SG01HP3-EU-DM2 |
SUN-6K-SG01HP3
-EU-DM2 |
SUN-8K-SG01HP3
-EU-DM2 |
SUN-10K-SG01HP3
-EU-BDM2 |
SUN-12K-SG01HP3
-EU-DM2 |
| Battery Input Data |
|
| Battery Type |
Lithium-ion |
| Battery Voltage Range(V) |
160-700 |
| Max.Charging Current(A) |
37 |
| Max.Discharging Current(A) |
37 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of battery input |
1 |
| PV String Input Data |
|
|
Max. PV Access Power (W)
|
10000 |
12000 |
16000 |
20000 |
24000 |
| Max DC Input Power（W） |
8000 |
9600 |
12800 |
16000 |
19200 |
| Max DC Input Voltage（V） |
1000 |
| Start-up Voltage（V） |
180 |
| MPPT Voltage Range（V） |
150-850 |
| Rated DC Input Voltage(V) |
600 |
| Max Input Short-Circuit Current（A） |
18+18 |
| Max Operating PV Input Current（A） |
27+27 |
| No.of MPP Trackers/No.of String Per MPP Tracker |
2/1+1 |
| AC Input/Output Data |
|
| Rated AC Input/Output Active Power（W） |
50000 |
6000 |
8000 |
10000 |
12000 |
| Max AC Input/Output Apparent Power （VA） |
5500 |
6600 |
8800 |
11000 |
13200 |
| Peak Power (off-grid)（W） |
1.5 times of rated power,10s |
| Rated AC Input/Output Current（A） |
7.6/7.3 |
9.1/8.7 |
12.2/11.6 |
15.2/14.5 |
18.2/17.4 |
| Max AC Input/Output Current（A） |
8.4/8 |
10/9.6 |
13.4/12.8 |
16.7/16 |
20/19.2 |
| Max Continuous AC Passthrough (grid to load)（A） |
35 |
| Rated Input/Output Voltage/Range(V) |
220/380V，230/400V 0.85Un-1.1Un |
| Grid Connection Form |
3L+N+PE |
| Rated Input/Output Grid Frequency/Range |
50/45-55, 60/55-65 |
| Power Factor Adjustment Range |
0.8 leading-0.8 lagging |
| Total Current Harmonic Distortion THDi |
<3% (of nominal power) |
| DC Injection Current |
<0.5%ln |
| Efficiency |
|
| Max Efficiency |
97.60% |
| Euro Efficiency |
97.0% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
|
|
Integrated
|
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage
Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit
Interrupter (optional), Anti-islanding Protection, DC Switch, Insulation Impedance Detection,
Residual Current Detection
|
| Surge Protection Level |
TYPE II(DC), TYPE II(AC) |
| Interface |
|
| Communication Interface |
WIFI, RS485, CAN |
| General Data |
|
| Operating Temperature Range |
-40℃+60℃,＞45℃ Derating |
| Permissible Ambient Humidity |
0-100% |
| Permissible Altitude |
2000m |
| Noise |
≤ 45 |
| Ingress Protection(IP) Rating |
IP 65 |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
| Cabinet size（W*H*D）[mm] |
376*470*244.5（Excluding connectors and brackets） |
| Weight[kg] |
24
|
24.5 |
| Warranty |
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy |
| Type Of Cooling |
Natural Cooling |
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
