SUN-(3-8)K-SG06LP3-EU-CM2

Product Details Specifications

Three-Phase Hybrid Inverter Three-Phase Hybrid Inverter

Three-Phase Hybrid Inverter

SUN-3/4/5/6/8K-SG06LP3-EU-CM2

2 MPPTs
Support 20A
PV modules.

200%
PV Oversizing

0.0% Higher Efficiency

Time-of-Use
Electricity Strategy

AC Coupling

UPS-Grade Switching

Diesel Generator
Backup Power

Max.0
Units in Parallel

Flexible Low-Voltage Battery Compatibility

Battery voltage range of 0-0V.

[1]

Powerful Charge/
Discharge Current

Three-PhaseUnbalanced Output

200%

Peak Power Output (10s)

Upgraded LCD Panel

Compact &
Lightweight Design

Dual Built-In PWMCooling Fans^[2]

Protection Rating

200% PV Oversizing

Maximize energy harvest.

Powerful Charge/Discharge Current

Support heavy-load operations with ease.

Support 48V Low-Voltage Batteries

40-60V

Flexible low voltage battery compatibility product lineup

Higher Efficiency

Enabled by new SiC MOSFET.

Advanced &
Output Performance

100% Three Phase Unbalanced Output

Flexible phase level management.

200% Peak Power Output (10s)

Easily handle high start up loads.

Flexible Expansion &
Robust Protection Design

Time-of-Use Electricity Strategy

6 customizable charge/discharge time slots.

AC Coupling

Retrofit existing PV systems with ESS.

UPS-Grade Switching

Protect sensitive loads

Max.10 Units in Parallel

Build a larger-scale hybrid system as needed.

Diesel Generator Backup Power

Support diesel generator connection during power outages.

Deye Copilot

AI-driven automated electricity trading decisions.

SG05 VS SG06

NEW

SUN-6K-SG05LP3-EU-SM2

SUN-6K-SG06LP3-EU-CM2

35.2kg

Weight

20.8kg

386x660x250mm

Dimensions

334x545x220mm

≤55 dB

Noise

<45 dB

Green Industry Bright Future

Ensure access to affordable,reliable,sustainable
and modern energy for all

SUN-3/4/5/6/8K-SG06LP3-EU-CM2

Three Phase Hybrid Inverter | 3-8kW | 2 MPPT | LV Battery Supported

48V low voltage battery, transformer isolation design
AC couple to retrofit existing solar system
Max. 10 pcs parallel for on-grid and off-grid operation; support multiple batteries parallel
6 time periods for battery charging/discharging
Max. charging/discharging current of 190A
Support storing energy from diesel generator
100% unbalanced output, max. output up to 50% rated power for each phase

DOWNLOAD AREA

>> Download Datasheet << >> Download Manual 1 <<

Technical Specifications

SUN-(3-8)K-SG06LP3-EU-CM2
Feedback

Model	SUN-3K-SG06LP3-EU-CM2	SUN-4K-SG06LP3-EU-CM2	SUN-5K-SG06LP3-EU-CM2	SUN-6K-SG06LP3-EU-CM2	SUN-8K-SG06LP3-EU-CM2
Battery Input Data
Battery Type	Lead-acid or Lithium-ion
Battery Voltage Range (V)	40-60
Max. Charging/Discharging Current (A)	70	95	120	135	190
Charging Strategy forLi-ion Battery	Self-adaption to BMS
Number of Battery Input	1
PV String Input Data
Max. PV Access Power (W)	6000	8000	10000	12000	16000
Max. PV Input Power (W)	4800	6400	8000	9600	12800
Max. PV Input Voltage (V)	800
Start-up Voltage (V)	160
MPPT Voltage Range (V)	200-650
Rated PV Input Voltage (V)	550
Max. Operating PV Input Current (A)	20+20
Max. Input Short-Circuit Current (A)	30+30
No. of MPP Trackers/No. of Strings MPP Tracker	2/1+1
AC Input/Output Data
Rated AC Input/Output Active Power (W)	3000	4000	5000	6000	8000
Max. AC Input/Output Apparent Power (VA)	3300	4400	5500	6600	8800
Rated AC Input/Output Current (A)	4.6/4.4	6.1/5.8	7.6/7.3	9.1/8.7	12.2/11.6
Max. AC Input/Output Current (A)	5/4.8	6.7/6.4	8.4/8	10/9.6	13.4/12.8
Max. Continuous AC Passthrough (grid to load) (A)	45
Peak Power (off-grid) (W)	2 times of rated power, 10s
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Rated Input/Output Voltage	220/380V, 230/400V 0.85Un-1.1Un 3L+N+PE
Rated Input/Output Grid Frequency/Range(Hz)	50/45-55, 60/55-65
Total Current Harmonic Distortion THDi	<3% (of nominal power)
DC Injection Current	<0.5% In
Eﬃciency
Max. Efﬁciency	97.6%
Euro Efﬁciency	96.5%
MPPT Efﬁciency	>99%
Equipment Protection
Integrated	DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit Interrupter (AFCI) (optional), Anti-islanding Protection, DC Switch, Insulation Impedance Detection, Residual Current Detection
Surge Protection Level	TYPE II(DC),TYPE II(AC)
Interface
LCD/LED Display	LCD
Communication Interface	WIFI,RS485,CAN
General Data
Operating Temperature Range (℃)	-40 to +60℃, >45℃ Derating
Permissible Ambient Humidity	0-100%
Permissible Altitude	3000m
Noise (dB)	＜45
Ingress Protection(IP) Rating	IP 65
Inverter Topology	Non-Isolated (solar), Isolated (battery)
Over Voltage Category	OVC II(DC), OVC III(AC)
Cabinet Size (WxHxD mm)	334×545×220 (Excluding Connectors and Brackets)
Weight (kg)	20.8				21.9
Type of Cooling	Natural Cooling				Intelligent Air Cooling
Warranty	5 Years / Up to 10 Years* *Warranty period varies by installation country. Refer to the Warranty Policy for details.
Grid Regulation	IEC 61727, IEC 62116,CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25,G99,VDE-AR-N 4105
Safety / EMC Standard	IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
