SUN-35/40/45/50K-G-LV | 33-50kW | Three Phase | 4 MPPT | Low Voltage | 127/220Vac

Higher yields / Safe & Reliable / Smart / User-friendly

This series inverter is specially designed for 127/220Vac,133/230Vac three-phase system, providing rated power at 33KW, 40KW, 45KW, 50KW. Equipped with large LCD and buttons, easy to operate and maintenance. With compact design and high-power density, this series supports 1.3 DC/AC ratio, saving device investment.

Remotely shutdown function

Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye full series inverter products support remotely shutdown immediately when accident occurs.Setting parameters and FW update remotely, which makes PV plant O&M easier.

127/220Vac,133/230Vac and 60/50Hz, three phase system
4 MPP tracker, Max. efficiency up to 98.7%
Zero export application, VSG application
String intelligent monitoring (optional)
Wide output voltage range
Anti-PID function (Optional)

DOWNLOAD AREA

>> Download Datasheet << >> Download Manual <<

Technical Specifications

SUN-35K-G-LV
SUN-40K-G-LV
SUN-45K-G-LV
SUN-50K-G-LV
Feedback

Model	SUN-35K-G02-LV	SUN-40K-G-LV	SUN-45K-G-LV	SUN-50K-G-LV	SUN-33K -G-LV	SUN-35K -G-LV	SUN-40K -G-LV	SUN-45K -G-LV	SUN-50K -G-LV
Input Side
Max. DC Input Power(kW)	45.5	52	58.5	65	42.9	45.5	52	58.5	65
Max. DC Input Voltage (V)	800
Start-up DC Input Voltage(V)	250
MPPT Operating Range(V)	200~700
Max. DC Input Current(A)	30+30+30+30	40+40+40+40
Max. Short Circuit Current (A)	45+45+45+45	60+60+60+60
No.of MPP Trackers	4
No.of Strings per MPP Tracker	3+3+3+3	4+4+4+4			3+3+3+3		4+4+4+4

Output Side
Rated Output Power(kW)	35	40	45	50	33	35	40	45	50
Max. Active Power(kW)	38.5	44	49.5	55	33	35	40	45	50
Nominal Output Voltage / Range (V)	3L/N/PE 127V/220V				3L/N/PE 133V/230V
Rated Grid Frequency (Hz)	60Hz/55Hz-65Hz				50Hz/45Hz-55Hz
Operating Phase	Three phase
Rated AC Grid Output Current(A)	91.9	104.9	118.1	131.2	82.8	87.8	100.3	112.8	125.4
Max. AC Output Current(A)	101.1	115.5	129.9	144.4	82.8	87.8	100.3	112.8	125.4
Output Power Factor	0.8 leading to 0.8 lagging
Grid Current THD	<3%
DC Injection Current(mA)	<0.5%

Efficiency
Max.Efficiency	98.7%
Euro Efficiency	98.3%
MPPT Efficiency	>99%

Protection
DC Reverse-Polarity Protection	Yes
AC Short Circuit Protection	Yes
AC Output Overcurrent Protection	Yes
Output Overvoltage Protection	Yes
Insulation Resistance Protection	Yes
Ground Fault Monitoring	Yes
Islanding Protection	Yes
Temperature Protection	Yes
Integrated DC Switch	Yes
Remote software upload	Yes
Remote change of operating parameters	Yes
Surge protection	DC Type II / AC Type II

General Data
Cabinet Size (WxHxD mm)	700×575×297 (Excluding Connectors and Brackets)
Weight(kg)	60
Topology	Transformerless
Internal Consumption	<1W(Night)
Running Temperature	-25~65℃, >45℃ Derating
Ingress Protection	IP65
Noise Emission(Typical)	<55 dB
Cooling Concept	Smart cooling
Max. Operating Altitude Without Derating	2000m
Warranty	5 Years
Grid Connection Standard	VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150
Operating Surroundings Humidity	0-100%
Safety EMC/Standard	IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

Features
DC Connection	MC-4 mateable
AC Connection	IP65 rated plug
Display	LCD 240 × 160
Interface	RS485/RS232/Wifi/LAN
