| Model |
SUN-1K-G04P1-EU-CM1 |
SUN-1.5K-G04P1-EU-CM1 |
SUN-2K-G04P1-EU-CM1 |
SUN-2.2K-G04P1-EU-CM1 |
SUN-2.5K-G04P1-EU-CM1 |
SUN-2.7K-G04P1-EU-CM1 |
SUN-3K-G04P1-EU-CM1 |
SUN-3.3K-G04P1-EU-CM1 |
SUN-3.6K-G04P1-EU-CM1 |
SUN-4K-G04P1-EU-CM1 |
| PV String Input Date |
| Max. PV Input Power(kW) |
1.3 |
2 |
2.6 |
2.9 |
3.3 |
3.5 |
3.9 |
4.3 |
4.7 |
5.2 |
| Max. PV Input Voltage(V) |
550 |
| Start-up Voltage(V) |
80 |
| MPPT Voltage Range(V) |
70-500 |
| Rated PV Input Voltage(V) |
360 |
420 |
| Max. Operating PV Input Current (A) |
20 |
| Max. Input Short Circuit Current (A) |
30 |
| No. of MPP Trackers/No. of Strings MPP Tracker |
1/1 |
| AC Output Side |
| Rated AC Output Active Power (kW) |
1 |
1.5 |
2 |
2.2 |
2.5 |
2.7 |
3 |
3.3 |
3.6 |
4 |
|
Max. AC Output Apparent Power (kVA)
|
1.1 |
1.65 |
2.2 |
2.42 |
2.75 |
2.97 |
3.3 |
3.63 |
3.96 |
4.4 |
|
Rated AC Output Current (A)
|
4.6/4.4 |
6.8/6.5 |
9.1/8.7 |
10/9.6 |
11.4/10.9 |
12.3/11.8 |
13.7/13.1 |
15/14.4 |
16.4/15.7 |
18.2/17.4 |
|
Max. AC Output Current (A)
|
5/4.8 |
7.5/7.2 |
10/9.6 |
11/10.6 |
12.5/12 |
13.5/13 |
15/14.4 |
16.5/15.8 |
18/17.3 |
20/19.2 |
|
Rated output voltage
|
220/230 0.85Un-1.1Un L/N/PE |
|
Rated Output Grid Frequency/Range(Hz)
|
50/45-55, 60/55-65
|
|
Power Factor Adjustment Range
|
0.8 leading to 0.8 lagging
|
|
Total Current Harmonic Distortion THDi
|
<3%
|
|
DC Injection Current
|
<0.5%ln
|
| Efficiency |
| Max. Efficiency |
97.3%
|
97.5% |
|
Euro Efficiency
|
96.9%
|
97.0% |
|
MPPT Efficiency
|
>99%
|
| Equipment Protection |
| DC Reverse Polarity Protection |
Yes |
| AC Output Overcurrent Protection |
Yes |
| AC Output Overvoltage Protection |
Yes |
| AC Output Short Circuit Protection |
Yes |
| Thermal Protection |
Yes |
| Insulation Impedance Detection |
Yes |
| DC Component Monitoring |
Yes |
| Arc Fault Circuit Interrupter (AFCI) |
Optional |
| Anti-islanding Protection |
Yes |
| Residual Current Detection |
Yes |
| DC Switch |
Yes |
| Surge Protection Level |
TYPE II(DC),TYPE II(AC) |
| Interface |
| LCD/LED Display |
LCD1602 |
| Communication Interface |
RS485/RS232/WiFi/LAN |
| General Data |
| Operating Temperature Range (°C) |
-25 to +65℃, >45℃ Derating |
| Permissible Ambient Humidity |
0~100% |
| Permissible Altitude |
3000m |
| Noise (dB) |
≤ 35 |
| Ingress Protection(IP) Rating |
IP 65 |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
| Cabinet Size (WxHxD mm) |
280*272.5*171.5（Excluding Connectors and Brackets） |
| Weight [kg] |
5.6 |
| Warranty |
5 Years |
| Type Of Cooling |
Natural Cooling |
| Grid Regulation |
IEC 61727,IEC 62116,CEI 0-21,EN 50549，NRS 097,RD 140,UNE 217002,G98,G99,VDE-AR-N 4105 |
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
